DH-IPC-B1E20P-A-0280B
Уличная цилиндрическая IP-видеокамера с ИК-подсветкой до 30м, 2Мп; 1/3.2” CMOS; 2.8мм; ИК-фильтр; 0.01лк@F2.2; сжатие: H.265+, H.265, H.264+, H.264, MJPEG; 2 потока до 2Мп@25к/с; DWDR; 3D NR; BLC, HLC; Smart подсветка; встроенный микрофон; защита: IP67; 12В(DC), PoE; корпус: пластик
Производитель: Dahua Technology
- Код:
- 00059141
- Базовая единица
- шт
2 890 руб.
Уличная цилиндрическая IP-видеокамера с ИК-подсветкой до 30м
- 2Мп; 1/3.2” CMOS; 2.8мм
- ИК-фильтр; 0.01лк@F2.2
- сжатие: H.265+, H.265, H.264+, H.264, MJPEG
- 2 потока до 2Мп@25к/с
- DWDR; 3D NR; BLC, HLC; Smart подсветка
- встроенный микрофон
- защита: IP67
- 12В(DC), PoE
- корпус: пластик
Технические характеристики
| Camera | |
| Image Sensor | 1/3.2" CMOS |
| Max. Resolution | 1920 (H) × 1080 (V) |
| ROM | 16 MB |
| RAM | 64 MB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination |
0.01 lux@F2.2 (Color, 30 IRE) 0.005 lux@F2.2 (B/W,30 IRE) 0 lux (Illuminator on) |
| S/N Ratio | >56 dB |
| Illumination Distance | Up to 30 m (98.43 ft) (IR LED) |
| Illuminator On/Off Control | Auto;Manual |
| Illuminator Number | 2 (IR LED) |
| Angle Adjustment |
Pan: 0°–360° Tilt: 0°–90° Rotation: 0°–360° |
| Lens | |
| Lens Type | Fixed-focal |
| Lens Mount | M12 |
| Focal Length | 2.8 mm; |
| Max. Aperture | F2.2 |
| Field of View |
2.8 mm: H: 99°; V: 55°; D: 117° |
| Iris Control | Fixed |
| Close Focus Distance |
2.8 mm: 0.5 m (1.64 ft) |
|
DORI Distance Lens Detect Observe Recognize Identify |
2.8 mm 44.7 m (146.65 ft) 17.9 m (58.73 ft) 8.9 m(29.20 ft) 4.5 m(14.76 ft) |
| Video | |
| Video Compression | H.265; H.264; H.264B; MJPEG (Only supported by the sub stream) |
| Smart Codec | Smart H.265+; Smart H.264+ |
| Video Frame Rate |
Main stream: 1920 × 1080@(1–25/30 fps) Sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) |
| Stream Capability | 2 streams |
| Resolution | 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240) |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate |
H.264: 32 kbps–4096 kbps H.265: 12 kbps–4096 kbps |
| Day/Night | Auto(ICR)/Color/B/W |
| BLC | Yes |
| HLC | Yes |
| WDR | DWDR |
| White Balance | Auto; natural; street lamp; outdoor; manual; regional custom |
| Gain Control | Auto |
| Noise Reduction | 3D NR |
| Motion Detection | OFF/ON (4 areas, rectangular) |
| Region of Interest (RoI) | Yes (4 areas) |
| Smart Illumination | Yes |
| Image Rotation | 0°/180° |
| Mirror | Yes |
| Privacy Masking | 4 areas |
| Alarm | |
| Alarm Event | Network disconnection; IP conflict; illegal access; motion detection; audio detection; video tampering; security exception |
| Network | |
| Network Port | RJ-45 (10/100 Base-T) |
| Network Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast; P2P |
| Interoperability | ONVIF (Profile S; Profile T); CGI |
| User/Host | 6 (Total bandwidth: 24 M) |
| Storage | FTP |
| Browser | IE; Chrome; Firefox |
| Management Software | Smart PSS Lite; DSS; DMSS |
| Mobile Client | iOS;Android |
| Cyber Security |
Configuration encryption; Trusted execution; Digest; Security logs; HTTPS; Trusted upgrade; WSSE; Trusted boot; Account lockout; Generation and importing of X.509 certification; Video encryption |
| Power | |
| Power Supply | 12 VDC/PoE |
| Power Consumption |
Basic: 1.2 W (12 VDC); 2.1 W (PoE) Max. (ICR switch+illuminator intensity): 2.8 W (12 VDC);4 W (PoE) |
| Environment | |
| Operating Temperature | –40 °C to +50 °C (–40 °F to +122 °F) |
| Operating Humidity | ≤95% |
| Storage Temperature | –40 °C to +60 °C (–40 °F to +140 °F) |
| Storage Humidity | ≤95% |
| Protection | IP67 |
| Structure | |
| Casing Material | Plastic |
| Product Dimensions | 198.9 mm × 80.2 mm × 76.2 mm (7.83" × 3.16" × 3.00") (L × W × H) |
| Net Weight | 0.25 kg (0.55 lb) |
| Gross Weight | 0.37 kg (0.82 lb) |
